Mapping and measuring urban places: Are we there yet? (Part 2/2)

This page in:
Photo by Anton Balazh via Shutterstock

My previous blog post surveyed some of the recent trends in developing global measures of urbanization. In this post, I want to turn to a brief discussion for scholars and practitioners on some possible applications and areas of focus for ongoing work:
[Download draft paper "Bright Lights, Big Cities: a Review of Research and Findings on Global Urban Expansion"]
While there are a number of different maps for documenting urban expansion, each has different strengths and weaknesses in application. Coarser resolution maps such as MODIS can be used for mapping the basic contours of artificial built-up areas in regional and comparative scales. On the other hand, high-resolution maps are best suited for individual cities, as algorithms can be used to identify and classify observed colors, textures, shading, and patterns into different types of land uses. These levels of detail are difficult to use for reliable comparisons between cities as the types of building materials, structure shapes, light reflectivity, and other factors can vary widely between countries and regions.
Nonetheless, there are a number of applications for policymakers in this regard, from identifying and mapping green spaces and natural hazard risks to identifying and tracking areas of new growth, such as informal settlements. However, such approaches to land use detection require careful calibration of these automated methods, such as cross referencing with other available maps, or by “ground truthing” with a sample of  street-level photos of various types of buildings and land cover as reference inputs for automation. One solution to this is the use of social media and geo-coded data to confirm and monitor changes in urban environments alongside the use of high-resolution satellite imagery.
Nighttime light maps also have gained traction as measures of urban extent and as ways to gauge changes in economic activity in large urban centers. They are probably less useful for documenting smaller settlements, which may be dimmer or have little significant variation in brightness. It is important to correct these types of maps for “overglow” measurement effects—where certain light may “bleed” or obscure the shapes and forms of very large, bright urban areas in relation to adjacent smaller and dimmer settlements (newer VIIRs maps have made some important advances in correcting this).
Urban expansion varies by region, according to case study research using satellite maps. With some exceptions in East Asia, cities across the world are generally expanding in size and declining in population density. In Central Asia, some cities are declining in population and nighttime light intensity, suggesting patterns of outmigration and changes in local economies. In most of Latin America and South Asia, urban population densities are in decline as urban built-up areas continue to expand outward or along transport corridorsn.
However, there has been relatively little comparative work classifying differences in the specific morphological dimensions of different urban forms, such as shapes, levels of centrality, density, and differences in shares of open space within built-up areas. Such analysis would provide deeper insight on correlations between different types of urban morphologies and other variables at the city or metropolitan level, such as the location and extent of informal settlements, access to services, economic activity and mobility, among others. Such research could begin to develop a typology of dimensions of urbanization, which can in turn be used for calibrating comparative land cover and urban population analyses.

A consensus is yet to be reached on population-based approaches to estimate global urban areas. While the use and application of gridded population data have improved the granularity of the spatial distribution of urban populations, there are several caveats. This is because gridded population sets each include different assumptions about estimating the distribution of urban populations in grid cells, which in turn effects the estimation of population “clusters.” In order to use these in a comparative context, analysts must supply and justify minimum population and/or population density thresholds to these clusters.
One of these techniques, the Agglomeration Index (used extensively in the 2009 World Development Report) uses different population thresholds and introduces a commuting catchment of 60 minutes from the city center. This is limited by the extent and availability of regular commuting data from across different countries. Nonetheless, it presents a consistent, functional definition of cities with an implicit spatial dimension. This provides a useful aperture for examining urban commuting patterns, transportation networks, and access to jobs.
When it comes to mapping and measuring urban places, we still have a long way to go.  We have, however, made much progress in refining both the map and population-based techniques for improving the consistency and accuracy of urban population and space measurements. Looking ahead, we need to develop ways to more closely merge a consistent measure of global urban built-up areas with reliable estimates of the populations contained within them.

What do you think? I welcome your thoughts and comments.


David Mason

Urban Development Specialist
